Machine Shop Services
DBC-110S Horizontal Boring Mill
Control Type: Fanuc
Spindle Size: 4.3"
Table Size: 63" x 55"
Max Weight On Table: 15,432 pounds
X-Horiz Tvl of Table: 78.7"
Y-Vert Tvl of Head: 59"
Z-Axis Travel: 47.2"
W-Axis Travel (Quill): 19.6"
B-Axis (Pallet Indexing): 0.001°
Rapid Traverse Rate (X/Y/Z/W): 473/473/473/236 ipm
Spindle Speed: 3,000 rpm
Spindle Motor: 35 hp
Spindle Taper: CAT 50
Tool Changer Capacity: 40
Coolant Thru Spindle: yes
Dimensions: 233" x 209" x 160"
Weight: 53,000 pounds
Puma 400/400L Lathe
Chuck Size: 18"
Bar Capacity: 4.62"
# Axis: 2
Power: 50 hp
Max RPM: 2,000 RPM
Turning Dia: 21.7"
Swing: 27.5"
Machining Length: 85.4"
Tailstock: Yes
Control: CNC (Fanuc 18T)
HAAS VF-7 Vertical Mill
X: 84"
Y: 32"
Z: 30"
Power: 30 hp
RPM: 7,500 RPM
# ATC: 30
Table-W: 28"
Table-L: 84"
Taper: CT or BT 50
# Axis: 3
Control: CNC (HAAS)
DHP-5500 Horizontal Mill
X: 31"
Y: 27"
Z: 29"
Power: 30 hp
RPM: 10,000 RPM
# ATC: 90
Pallet-W: 20"
Pallet-L: 20"
Taper: CAT 50
Control: CNC (FANUC 18i-MB)
Dimensions: 197" X 130" X 126"
Weight: 38,350 LBS
Puma 2500LY Lathe w/ Live Tooling Capability
Chuck Size": 19"
Bar Capacity: 3.02"
# Axis: 4
Power: 30 hp
Max RPM: 3,500 RPM
Turning Dia: 13"
Swing: 23.6"
Machining Length: 32.6"
Tailstock: Yes
Control: CNC (FANUC 18iT-B)
Manual Machine Services
Cincinnatti "Super Duty" 5' Radial Arm Drill
For drilling of larger, deeper holes.
Kingston HJ-1700 Lathe
Kingston KMT-5V Mill
